Importing FSX aircraft to use as static objects in MSFS?

retnavycpo

retnavycpo

Messages
26
Country
us-florida
I had messaged Ron Zambrano (Razbam) for permission to use his A-7 series models to create static aircraft for MSFS. He gave me the "go ahead", and one of the members on Flightsim.to converted it for me.I found several tutorials on YouTube about importing aircraft from FSX into MSFS, but haven't located videos that specifically mention simply converting FSX to static aircraft for MSFS. I do know that Model Converter X (and I believe the Legacy Converter tool) are used to accomplish the task, but so far I have not grasped how to do it.Then I wondered if the SAMM (Static Aircraft Model Maker) tool would somehow be useful in this regard? I know it was made for FSX & P3D, but wondered if the "end product" of using that tool could THEN be converted somehow and THEN be imported into MSFS.If I can learn how to do this (major feat for me at least), then I would learn how to actually import them into MSFS sceneries and populate empty flightlines. A friend of mine on Discord has agreed to take on the job of recreating NAS Cecil Field (KVQQ) for MSFS. With the conversion of Razbam's A-7Es to static objects for almost all of Cecil Field SLUF squadron's, the flight line will look awesome! I have wanted this base scenery done again, ever since John Stinstrom did his version for FSX so long ago.I have provided all the info on Cecil that I could glean from the internet (sites such as the Ghost Bases), plus Facebook groups and memorabilia that I have saved from my time there. Really am looking forward to this. NC

Conversion is doable but pretty tedious imo. I think it's easier to start from "scratch," as in using a freeware model and then just patching in components of MSFS parts to make the aircraft presentable taxiing around. I say this because animations, for example, won't convert across. They might, but Arno has a hard block on them in MCX and that's the only built up tool that will do it, so presumably you could just use the different softwares MCX calls, do the same thing yourself - or -start over with an static model and Asobo parts.
So you could take the default Hornet from acceleration, use MCX to remove all the bits you won't see or need and then study the MSFS SDK on how to make an aircraft. You could research my posts, I made a pretty extensive instructional thread about converting static models to AI aircraft. The black J-20 below is composed using a model I purchased on Sketchfab and the MSFS default Hornet landing gear, fully animated of course. I've made 4 of these or so, three you can chase around in my South China Sea scenery, available at flightsim.to and one I'll give you, an EF-18 Growler, if you end up making NAS Whidbey Island KNUW for MSFS.

AI In flight.jpg

AIr Force.jpg



At least for now, my only goal is to convert a S-3 Viking model to use as static in MSFS. I was hoping to use Dino's S-3, couldn't get approval. So next choice may be a earlier model. Not sure if Kazourni Ito did one. I believe Mark Rooks did. Animations not needed. The main reason I had hoped to use Dino's is because there are a lot of paints for it.

Static aircraft can be cranked out with MCX, just cycle the animations to the parking positions and freeze (fix) them. You'll have to change texture formats, set up the right file structure, MCX can do it all but it's not automatic. Again the SDK helps and there's a lot of posts here about it. As far as static models, there's the freeware Iris one and there's one at the Trimble Warehouse that's ok.

I have done this exact same thing.
Firstly I used MSX to 'extract' the model when I then imported into BLENDER when I 'cleaned' up the model by removing animations, and also used the modifier 'decimate' to reduce the number of faces/triangles etc.

If you haven't already have a look at this video although I believe it describes how to make a flyable versions not a staric version which isn't a lot different.


Also have a look at this video


Last edited:
Trying to get MCX to import then export to FSX Mdl in preparation to convert to MSFS.
I'm getting error messages in MCX Re DirectX 9 etc. see my other post.
www.fsdeveloper.com

Error messages with MCX

I'm trying to make a couple of static aircraft for MSFS and have a model as a gltf. I can import this to MCX but can't seem to export to FSX mdl? (I was hoping if I got the model to FSX I could then "convert" it to MSFS). I keep getting error messages in MCX - see attached. The Direct X9 issue I...
www.fsdeveloper.com www.fsdeveloper.com
Any help would be appreciated.
